Rod Mill Grinding Rod

Every Rod Mill Grinding Rod undergoes strict quality inspections, including surface hardness testing, straightness checks, and impact resistance evaluation. This ensures that the Rod Mill Grinding Rod delivers stable wear performance, low breakage rates (≤1%), and reliable operation across extended service periods.

Contact Now E-Mail Telephone WhatsApp

Product Details

Product Display

The Rod Mill Grinding Rod is manufactured from selected high-quality steel and processed through advanced heat treatment to achieve optimal hardness and toughness. This allows the Rod Mill Grinding Rod to resist bending and breaking under continuous grinding pressure, making it ideal for both dry and wet rod mills.

Industry Applications

Machines	Industries
·Rod mills	·Mining industry
·Bar mills	·Power stations
	·Cement industry
	·Quartz/Silica sand factory
	·Coal Chemical Industry
	·Metallurgical industry

Technical Specifications Guide

Chemical Composition (%)
Steel Specification	C	Mn	Si	Cr	S	P
40Cr	0.37-0.44	0.50-0.80	0.17-0.37	0.80-1.15	≤0.035	≤0.035
42CrMo	0.38-0.45	0.50-0.80	0.17-0.37	0.90-1.25	≤0.035	≤0.035
#45/C45	0.42-0.54	0.50-0.80	0.17-0.37	≤0.15	≤0.035	≤0.035
60Mn	0.57-0.65	0.70-1.00	0.17-0.37	≤0.25	≤0.035	≤0.035
65Mn	0.62-0.72	0.90-1.20	0.17-0.37	≤0.25	≤0.035	≤0.035
B2	0.70-0.92	0.70-1.00	0.17-0.37	0.40-0.70	≤0.035	≤0.035
B3	0.52-0.65	0.66-1.00	1.30-1.90	0.74-1.20	≤0.030	≤0.030
BU	0.95-1.05	0.95-1.05	0.15-0.35	0.45-0.55	≤0.035	≤0.035
BL	0.55-0.75	0.65-0.85	0.15-0.35	0.70-1.20	≤0.035	≤0.035
BG	0.90-1.05	0.35-0.95	0.15-0.35	1.00-1.70	≤0.035	≤0.035

Physical Features
Steel Specification	Impact Value (J/cm²)	Surface Hardness (HRC)	Diameter (mm)	Length (mm)	Broken Rod Rate (%)	Diameter Tolerance (mm)	Length Tolerance (mm)
40Cr	≥12	45-60	25-140	1500-6000	≤1	±1.5	±20
42CrMo
#45/C45
60Mn
65Mn
B2
B3
BU
BL
BG

Quality Supervision System

Manufacturing Environment

Plants and Production Equipment

Trade Fair Participation

Exhibitions

Cooperation Highlights

With customizable lengths from 2 to 6 meters and diameters ranging from 30mm to 120mm, the Rod Mill Grinding Rod offers excellent adaptability to various grinding applications. Each Rod Mill Grinding Rod maintains precise dimensions and straightness, ensuring efficient grinding performance and consistent particle size reduction.
