3.5 Forged Ball

The 3.5 Forged Ball is manufactured through high-temperature forging followed by precision heat treatment, ensuring a compact internal structure and high mechanical strength. This process gives the 3.5 Forged Ball superior resistance to wear, impact, and fatigue, making it well-suited for heavy-duty grinding operations in mining and cement industries.

Contact Now E-Mail Telephone WhatsApp

Product Details

Introduction to Our Products

Thanks to strict control over raw materials and forging parameters, the 3.5 Forged Ball maintains excellent hardness uniformity from surface to core. This consistency reduces the risk of premature breakage and helps the 3.5 Forged Ball deliver stable performance over long grinding cycles, even under high-impact conditions.

3.5 Forged Ball

Application Scenarios

Machines	Industries
·Ball mills	·Mining industry
·SAG mills	·Power stations
·Tower mills	·Cement industry
·Coal grinding machine	·Steel Industry
·Bearing	·Chemical Industry
	·Metallurgical industry

Performance Specifications

Chemical Composition (%)
Steel Specification	C	Mn	Si	Cr	S	P
40Cr	0.37-0.44	0.50-0.80	0.17-0.37	0.80-1.15	≤0.035	≤0.035
42CrMo	0.38-0.45	0.50-0.80	0.17-0.37	0.90-1.25	≤0.035	≤0.035
60Mn	0.57-0.65	0.70-1.00	0.17-0.37	≤0.25	≤0.035	≤0.035
65Mn	0.62-0.72	0.90-1.20	0.17-0.37	≤0.25	≤0.035	≤0.035
ZT-4	0.44-0.72	0.50-0.90	0.17-0.37	≤0.50	≤0.035	≤0.035
ZT-10	0.60-0.78	0.65-1.33	0.25-0.65	≤0.45	≤0.035	≤0.035
B2	0.70-0.92	0.70-1.00	0.17-0.37	0.40-0.70	≤0.035	≤0.035
B3	0.52-0.65	0.66-1.00	1.30-1.90	0.74-1.20	≤0.030	≤0.030
B4	0.65-0.75	0.50-0.70	1.20-1.40	0.85-1.00	≤0.025	≤0.025
B6	0.75-0.90	0.80-1.02	0.17-0.37	0.88-0.98	≤0.035	≤0.035
BU	0.95-1.05	0.95-1.05	0.15-0.35	0.45-0.55	≤0.035	≤0.035
BL	0.55-0.75	0.65-0.85	0.15-0.35	0.70-1.20	≤0.035	≤0.035
BG	0.90-1.05	0.35-0.95	0.15-0.35	1.00-1.70	≤0.035	≤0.035

Physical Features
Diameter (mm) (inches)	Surface Hardness (HRC)	Diameter Tolerance (mm)	Impact Value (J/cm²)	Breakage Rate (%)	Drop Test (times)
20 (0.79)	>60	+2.0 -1.0	≥12	≤1	>15000
25 (0.98)
30 (1.18)
40 (1.57)
50 (1.97)
60 (2.36)		+3.0 -1.5
65(5.56)
70 (2.76)
75 (3.00)
80 (3.15)
90 (3.54)
100 (3.94)		+4.0 -2.0
120 (4.72)	>58
125 (4.92)
140 (5.51)	>55	+5.0 -3.0
150 (5.91)

Quality Standards and Inspection

Production Infrastructure

Plants and Production Equipment

Exhibition Activities

Exhibitions

Collaboration Advantages

Each 3.5 Forged Ball is subject to rigorous quality checks to guarantee precise diameter and roundness. With a standard size of approximately 90mm, the 3.5 Forged Ball ensures smooth rotation inside the mill, promotes efficient ore fragmentation, and contributes to overall plant productivity.
