High Quality Grinding Balls for Ball Mill Mining
Our High Quality Grinding Balls for Ball Mill Mining are designed to deliver excellent wear resistance and impact strength under demanding milling conditions. The optimized hardness distribution improves grinding efficiency while minimizing ball consumption, helping mining operations maintain stable performance and reduce operational costs over long production cycles.
Product Introduction
The High Quality Grinding Balls for Ball Mill Mining are manufactured using selected alloy steel materials combined with advanced forging and controlled heat-treatment technology. This process ensures a dense internal structure, accurate dimensions, and consistent mechanical performance suitable for modern grinding systems.
Wide Application
Machines | Industries |
·Ball mills | ·Mining industry |
·SAG mills | ·Power stations |
·Tower mills | ·Cement industry |
·Coal grinding machine | ·Steel Industry |
·Bearing | ·Chemical Industry |
·Metallurgical industry |
Our High Quality Grinding Balls for Ball Mill Mining are widely applied in gold, copper, iron ore, and other mineral processing plants. They perform efficiently in both SAG mills and ball mills, adapting well to different ore hardness levels and grinding environments.
Technical Performance
Chemical Composition (%) | ||||||
Steel Specification | C | Mn | Si | Cr | S | P |
40Cr | 0.37-0.44 | 0.50-0.80 | 0.17-0.37 | 0.80-1.15 | ≤0.035 | ≤0.035 |
42CrMo | 0.38-0.45 | 0.50-0.80 | 0.17-0.37 | 0.90-1.25 | ≤0.035 | ≤0.035 |
60Mn | 0.57-0.65 | 0.70-1.00 | 0.17-0.37 | ≤0.25 | ≤0.035 | ≤0.035 |
65Mn | 0.62-0.72 | 0.90-1.20 | 0.17-0.37 | ≤0.25 | ≤0.035 | ≤0.035 |
ZT-4 | 0.44-0.72 | 0.50-0.90 | 0.17-0.37 | ≤0.50 | ≤0.035 | ≤0.035 |
ZT-10 | 0.60-0.78 | 0.65-1.33 | 0.25-0.65 | ≤0.45 | ≤0.035 | ≤0.035 |
B2 | 0.70-0.92 | 0.70-1.00 | 0.17-0.37 | 0.40-0.70 | ≤0.035 | ≤0.035 |
B3 | 0.52-0.65 | 0.66-1.00 | 1.30-1.90 | 0.74-1.20 | ≤0.030 | ≤0.030 |
B4 | 0.65-0.75 | 0.50-0.70 | 1.20-1.40 | 0.85-1.00 | ≤0.025 | ≤0.025 |
B6 | 0.75-0.90 | 0.80-1.02 | 0.17-0.37 | 0.88-0.98 | ≤0.035 | ≤0.035 |
BU | 0.95-1.05 | 0.95-1.05 | 0.15-0.35 | 0.45-0.55 | ≤0.035 | ≤0.035 |
BL | 0.55-0.75 | 0.65-0.85 | 0.15-0.35 | 0.70-1.20 | ≤0.035 | ≤0.035 |
BG | 0.90-1.05 | 0.35-0.95 | 0.15-0.35 | 1.00-1.70 | ≤0.035 | ≤0.035 |
Physical Features | |||||
Diameter (mm) (inches) | Surface Hardness (HRC) | Diameter Tolerance (mm) | Impact Value (J/cm²) | Breakage Rate (%) | Drop Test (times) |
20 (0.79) | >60 | +2.0 -1.0 | ≥12 | ≤1 | >15000 |
25 (0.98) | |||||
30 (1.18) | |||||
40 (1.57) | |||||
50 (1.97) | |||||
60 (2.36) | +3.0 -1.5 | ||||
65(5.56) | |||||
70 (2.76) | |||||
75 (3.00) | |||||
80 (3.15) | |||||
90 (3.54) | |||||
100 (3.94) | +4.0 -2.0 | ||||
120 (4.72) | >58 | ||||
125 (4.92) | |||||
140 (5.51) | >55 | +5.0 -3.0 | |||
150 (5.91) | |||||
Strict Quality Inspection
Each batch of High Quality Grinding Balls for Ball Mill Mining undergoes strict inspection including hardness testing, impact testing, and drop testing to ensure compliance with customer requirements. Comprehensive quality control guarantees consistent performance and reliable service life.
Manufacturing Process
Exhibition Presence
We actively promote our High Quality Grinding Balls for Ball Mill Mining at international mining exhibitions and industry events worldwide. Through face-to-face communication with global partners, we continuously strengthen technical cooperation and expand long-term business relationships.
Why Choose Us
Choosing our High Quality Grinding Balls for Ball Mill Mining means working with a manufacturer focused on stable quality, efficient production, and fast delivery capability. We aim to provide dependable grinding media solutions that improve milling efficiency and support sustainable mining operations.
