Forged Ball for Mining Company
Forged Ball for Mining Company is designed to support stable grinding performance under continuous mill operation. The forged structure helps the ball withstand repeated impact and rolling forces, contributing to steady milling efficiency and reliable performance in daily mining production.
Product Introduction
Forged Ball for Mining Company is manufactured from selected steel materials through heating, forging, and controlled processing. The forging method improves internal density and balance, allowing the grinding ball to work smoothly inside ball mills commonly used in mining operations.
Wide Application
Machines | Industries |
·Ball mills | ·Mining industry |
·Power stations | |
·Tower mills | ·Cement industry |
·Coal grinding machine | ·Steel Industry |
·Bearing | ·Chemical Industry |
·Metallurgical industry |
Forged Ball for Mining Company is widely used in gold, copper, iron, and other mineral processing plants. It performs well in both wet and dry grinding environments and adapts to different ore types, production scales, and operating conditions across mining sites.
Technical Performance
Chemical Composition (%) | ||||||
Steel Specification | C | Mn | Si | Cr | S | P |
40Cr | 0.37-0.44 | 0.50-0.80 | 0.17-0.37 | 0.80-1.15 | ≤0.035 | ≤0.035 |
42CrMo | 0.38-0.45 | 0.50-0.80 | 0.17-0.37 | 0.90-1.25 | ≤0.035 | ≤0.035 |
60Mn | 0.57-0.65 | 0.70-1.00 | 0.17-0.37 | ≤0.25 | ≤0.035 | ≤0.035 |
65Mn | 0.62-0.72 | 0.90-1.20 | 0.17-0.37 | ≤0.25 | ≤0.035 | ≤0.035 |
ZT-4 | 0.44-0.72 | 0.50-0.90 | 0.17-0.37 | ≤0.50 | ≤0.035 | ≤0.035 |
ZT-10 | 0.60-0.78 | 0.65-1.33 | 0.25-0.65 | ≤0.45 | ≤0.035 | ≤0.035 |
B2 | 0.70-0.92 | 0.70-1.00 | 0.17-0.37 | 0.40-0.70 | ≤0.035 | ≤0.035 |
B3 | 0.52-0.65 | 0.66-1.00 | 1.30-1.90 | 0.74-1.20 | ≤0.030 | ≤0.030 |
B4 | 0.65-0.75 | 0.50-0.70 | 1.20-1.40 | 0.85-1.00 | ≤0.025 | ≤0.025 |
B6 | 0.75-0.90 | 0.80-1.02 | 0.17-0.37 | 0.88-0.98 | ≤0.035 | ≤0.035 |
BU | 0.95-1.05 | 0.95-1.05 | 0.15-0.35 | 0.45-0.55 | ≤0.035 | ≤0.035 |
BL | 0.55-0.75 | 0.65-0.85 | 0.15-0.35 | 0.70-1.20 | ≤0.035 | ≤0.035 |
BG | 0.90-1.05 | 0.35-0.95 | 0.15-0.35 | 1.00-1.70 | ≤0.035 | ≤0.035 |
Physical Features | |||||
Diameter (mm) (inches) | Surface Hardness (HRC) | Diameter Tolerance (mm) | Impact Value (J/cm²) | Breakage Rate (%) | Drop Test (times) |
20 (0.79) | >60 | +2.0 -1.0 | ≥12 | ≤1 | >15000 |
25 (0.98) | |||||
30 (1.18) | |||||
40 (1.57) | |||||
50 (1.97) | |||||
60 (2.36) | +3.0 -1.5 | ||||
65(5.56) | |||||
70 (2.76) | |||||
75 (3.00) | |||||
80 (3.15) | |||||
90 (3.54) | |||||
100 (3.94) | +4.0 -2.0 | ||||
120 (4.72) | >58 | ||||
125 (4.92) | |||||
140 (5.51) | >55 | +5.0 -3.0 | |||
150 (5.91) | |||||
Strict Quality Inspection
Before delivery, Forged Ball for Mining Company goes through routine quality inspections. These checks focus on size accuracy, surface condition, and basic hardness range according to customer requirements, helping ensure consistent use during actual milling processes.
Manufacturing Process
Exhibition Presence
Forged Ball for Mining Company is regularly presented at international mining exhibitions and industry trade shows. These events provide opportunities to communicate directly with global clients, share application experience, and strengthen long-term cooperation in the mining sector.
Why Choose Us
Choosing Forged Ball for Mining Company means working with a supplier focused on stable supply and dependable service. With consistent production capacity, flexible specifications, and efficient delivery arrangements, we support mining companies in maintaining smooth and reliable grinding operations.
