Hot Rolled Forged Steel Grinding Ball
Hot Rolled Forged Steel Grinding Ball combines rolling and forging techniques to improve internal density and structural stability. This process enhances resistance to impact and abrasion inside the mill, helping maintain steady grinding performance during continuous mining operations.
Product Introduction
Hot Rolled Forged Steel Grinding Ball is manufactured from selected carbon or alloy steel through controlled heating, hot rolling, and forging procedures. The production method ensures uniform shape and consistent mechanical properties, making it suitable for use in ball mills across various mineral processing plants.
Wide Application
Machines | Industries |
·Ball mills | ·Mining industry |
·SAG mills | ·Power stations |
·Tower mills | ·Cement industry |
·Coal grinding machine | ·Steel Industry |
·Bearing | ·Chemical Industry |
·Metallurgical industry |
Hot Rolled Forged Steel Grinding Ball is widely used in gold, copper, iron, and other metal mining industries. It performs effectively in both wet and dry grinding systems and adapts to different ore hardness levels and operating conditions, supporting diverse milling requirements.
Technical Performance
Chemical Composition (%) | ||||||
Steel Specification | C | Mn | Si | Cr | S | P |
40Cr | 0.37-0.44 | 0.50-0.80 | 0.17-0.37 | 0.80-1.15 | ≤0.035 | ≤0.035 |
42CrMo | 0.38-0.45 | 0.50-0.80 | 0.17-0.37 | 0.90-1.25 | ≤0.035 | ≤0.035 |
60Mn | 0.57-0.65 | 0.70-1.00 | 0.17-0.37 | ≤0.25 | ≤0.035 | ≤0.035 |
65Mn | 0.62-0.72 | 0.90-1.20 | 0.17-0.37 | ≤0.25 | ≤0.035 | ≤0.035 |
ZT-4 | 0.44-0.72 | 0.50-0.90 | 0.17-0.37 | ≤0.50 | ≤0.035 | ≤0.035 |
ZT-10 | 0.60-0.78 | 0.65-1.33 | 0.25-0.65 | ≤0.45 | ≤0.035 | ≤0.035 |
B2 | 0.70-0.92 | 0.70-1.00 | 0.17-0.37 | 0.40-0.70 | ≤0.035 | ≤0.035 |
B3 | 0.52-0.65 | 0.66-1.00 | 1.30-1.90 | 0.74-1.20 | ≤0.030 | ≤0.030 |
B4 | 0.65-0.75 | 0.50-0.70 | 1.20-1.40 | 0.85-1.00 | ≤0.025 | ≤0.025 |
B6 | 0.75-0.90 | 0.80-1.02 | 0.17-0.37 | 0.88-0.98 | ≤0.035 | ≤0.035 |
BU | 0.95-1.05 | 0.95-1.05 | 0.15-0.35 | 0.45-0.55 | ≤0.035 | ≤0.035 |
BL | 0.55-0.75 | 0.65-0.85 | 0.15-0.35 | 0.70-1.20 | ≤0.035 | ≤0.035 |
BG | 0.90-1.05 | 0.35-0.95 | 0.15-0.35 | 1.00-1.70 | ≤0.035 | ≤0.035 |
Physical Features | |||||
Diameter (mm) (inches) | Surface Hardness (HRC) | Diameter Tolerance (mm) | Impact Value (J/cm²) | Breakage Rate (%) | Drop Test (times) |
20 (0.79) | >60 | +2.0 -1.0 | ≥12 | ≤1 | >15000 |
25 (0.98) | |||||
30 (1.18) | |||||
40 (1.57) | |||||
50 (1.97) | |||||
60 (2.36) | +3.0 -1.5 | ||||
65(5.56) | |||||
70 (2.76) | |||||
75 (3.00) | |||||
80 (3.15) | |||||
90 (3.54) | |||||
100 (3.94) | +4.0 -2.0 | ||||
120 (4.72) | >58 | ||||
125 (4.92) | |||||
140 (5.51) | >55 | +5.0 -3.0 | |||
150 (5.91) | |||||
Strict Quality Inspection
Before shipment, Hot Rolled Forged Steel Grinding Ball undergoes standard inspection procedures. Quality checks include dimensional verification, surface condition evaluation, and hardness testing to meet customer specifications and ensure reliable performance during actual grinding operations.
Manufacturing Process
Exhibition Presence
Hot Rolled Forged Steel Grinding Ball is regularly showcased at international mining exhibitions and industry trade events. These exhibitions provide opportunities to demonstrate product applications, exchange technical insights, and strengthen cooperation with clients from different regions.
Why Choose Us
Choosing Hot Rolled Forged Steel Grinding Ball means selecting a grinding media solution supported by stable manufacturing capability and consistent supply. With flexible specifications, dependable quality management, and responsive service, we help clients maintain efficient and reliable milling performance.
