Balls on Forged in Fire
Balls on Forged in Fire are known for their solid structure and reliable performance formed through high-temperature forging. The forging process improves overall strength and impact resistance, allowing the balls to perform steadily under demanding working conditions while maintaining consistent grinding efficiency.
Product Introduction
Balls on Forged in Fire are produced using controlled heating and shaping processes to ensure uniform shape and balanced internal quality. Available in various sizes, these forged balls are suitable for different mill types and grinding stages, offering flexible choices for diverse applications.
Wide Application
Machines | Industries |
·Ball mills | ·Mining industry |
·SAG mills | ·Power stations |
·Tower mills | ·Cement industry |
·Coal grinding machine | ·Steel Industry |
·Bearing | ·Chemical Industry |
·Metallurgical industry |
Balls on Forged in Fire are widely used in mining, mineral processing, and industrial grinding operations. Their adaptability allows them to handle various materials and operating conditions, making them a practical solution for both coarse and fine grinding environments.
Technical Performance
Chemical Composition (%) | ||||||
Steel Specification | C | Mn | Si | Cr | S | P |
40Cr | 0.37-0.44 | 0.50-0.80 | 0.17-0.37 | 0.80-1.15 | ≤0.035 | ≤0.035 |
42CrMo | 0.38-0.45 | 0.50-0.80 | 0.17-0.37 | 0.90-1.25 | ≤0.035 | ≤0.035 |
60Mn | 0.57-0.65 | 0.70-1.00 | 0.17-0.37 | ≤0.25 | ≤0.035 | ≤0.035 |
65Mn | 0.62-0.72 | 0.90-1.20 | 0.17-0.37 | ≤0.25 | ≤0.035 | ≤0.035 |
ZT-4 | 0.44-0.72 | 0.50-0.90 | 0.17-0.37 | ≤0.50 | ≤0.035 | ≤0.035 |
ZT-10 | 0.60-0.78 | 0.65-1.33 | 0.25-0.65 | ≤0.45 | ≤0.035 | ≤0.035 |
B2 | 0.70-0.92 | 0.70-1.00 | 0.17-0.37 | 0.40-0.70 | ≤0.035 | ≤0.035 |
B3 | 0.52-0.65 | 0.66-1.00 | 1.30-1.90 | 0.74-1.20 | ≤0.030 | ≤0.030 |
B4 | 0.65-0.75 | 0.50-0.70 | 1.20-1.40 | 0.85-1.00 | ≤0.025 | ≤0.025 |
B6 | 0.75-0.90 | 0.80-1.02 | 0.17-0.37 | 0.88-0.98 | ≤0.035 | ≤0.035 |
BU | 0.95-1.05 | 0.95-1.05 | 0.15-0.35 | 0.45-0.55 | ≤0.035 | ≤0.035 |
BL | 0.55-0.75 | 0.65-0.85 | 0.15-0.35 | 0.70-1.20 | ≤0.035 | ≤0.035 |
BG | 0.90-1.05 | 0.35-0.95 | 0.15-0.35 | 1.00-1.70 | ≤0.035 | ≤0.035 |
Physical Features | |||||
Diameter (mm) (inches) | Surface Hardness (HRC) | Diameter Tolerance (mm) | Impact Value (J/cm²) | Breakage Rate (%) | Drop Test (times) |
20 (0.79) | >60 | +2.0 -1.0 | ≥12 | ≤1 | >15000 |
25 (0.98) | |||||
30 (1.18) | |||||
40 (1.57) | |||||
50 (1.97) | |||||
60 (2.36) | +3.0 -1.5 | ||||
65(5.56) | |||||
70 (2.76) | |||||
75 (3.00) | |||||
80 (3.15) | |||||
90 (3.54) | |||||
100 (3.94) | +4.0 -2.0 | ||||
120 (4.72) | >58 | ||||
125 (4.92) | |||||
140 (5.51) | >55 | +5.0 -3.0 | |||
150 (5.91) | |||||
Strict Quality Inspection
Each batch of Balls on Forged in Fire is subjected to routine inspections, including appearance checks, size verification, and basic performance evaluation. These quality control steps help ensure consistent results and stable performance during long-term use.
Manufacturing Process
Exhibition Presence
Balls on Forged in Fire are regularly showcased at international mining and industrial exhibitions. Through exhibitions, customers can better understand product features, application scenarios, and manufacturing capabilities, strengthening communication and cooperation opportunities.
Why Choose Us
Choosing Balls on Forged in Fire means selecting forged products with stable quality, reliable supply, and proven application value. With continuous improvement and practical experience, Balls on Forged in Fire remain a dependable option for grinding operations across different industries.
